16' Cape Cod Semi Dory Plans

16′ Cape Cod Semi Dory Plans

Original price was: $80.80.Current price is: $48.13.

Category:

Description

The Cape Cod is a motor dory based upon the Swampscott model with it’s flat but rockered bottom panel and 4 planks per side. Unlike the sailing Swampscott, the bottom is kept fairly wide aft so that she can take a reasonable size of outboard (up to 35 hp). The plans show details for both the simple stitch and tape and clinker ply methods of construction and the standard fit-out shows a foredeck plus narrow side decks and storage both fore and aft. She could be fitted out with a cuddy or small cabin etc.

16 Cape Cod Dory Particulars
LOA 16′ 4.88m
Beam 6′ 1.83m
Hull Mid Depth 1’11” 0.58m
Draft 8″ 0.2m
Approx. Dry Weight 300 lbs 136 kg
Engine 4-35 hp
Hull Shape Dory – flat bottom plus 4 planks per side
Construction Methods Clinker ply, stitch and tape and strip plank
Major plywood requirements for hull 7 x 6mm sheets2 x 9mm sheets
Guidance Use 4-6 adults estuary/coastal
Drawing/Design Package 1 x A0 drawing + 3 x A1 drawings + 6 x A4 instruction/spec sheets
Additions and alterations included with the plans
